The GREC Series offers industrial-grade IP55 AC EV chargers (3.5kW & 7kW) with RFID smart card control for residential parking, hotels, and campsites.
The GREC Series AC EV Charging Piles provide reliable utility charging equipment designed for residential and commercial applications. Built with an industrial-grade design, these chargers are widely deployed in private parking spaces, residential lots, commercial complexes, industrial parks, hotels, and campsites. Featuring IP55 weather protection, smart RFID/card control, and multiple built-in electrical safety safeguards, they are suitable for systematic and lightweight charging layouts. The series supports both wall-mounted and pedestal-mounted installation configurations, allowing flexible adaptability to various local electrical standards and site-specific needs.
The charger delivers a smooth and stable current output to slow down vehicle battery degradation over extended periods of daily use. This moderate charging method is highly compatible with most EV models, making it an excellent choice for daily overnight home charging and commercial fleets.
Operating on standard single-phase 220V AC utility power, these chargers are highly compatible with residential grids, campsite utility lines, and rural properties. This makes power sourcing simple and cost-effective, while built-in electrical safeguards protect against overloads and grid surges.
Designed with low-noise cooling fans, the chargers operate quietly without high-frequency humming, ensuring overnight operation does not disturb residents or neighboring campers. The straightforward AC circuitry requires minimal maintenance, limiting upkeep to basic dust cleaning and cable inspections.
To accommodate diverse global market requirements, the chargers can be tailored with specific regional connector standards, rated currents, and custom enclosures. Distributors and fleet operators can also specify private branding, labeling, and custom colors.
| Specification |
|
|
|---|---|---|
| Model | GREC3.5KW-A | GREC7KW-SC |
| EV Charging Connector | 1 | 1 |
| Electrical Protection | Included (Short, Overload, Emergency Stop) | Included (Short, Overload, Emergency Stop) |
The primary difference between these models is the maximum charging power output (7kW vs. 3.5kW), allowing operators to match the equipment with local grid capacities and user charging speed requirements.
The GREC Series can be customized to meet the requirements of different commercial and residential charging projects. Customization options include:
| Specification | Details |
|---|---|
| Product Series | GREC Series |
| Material | Plastic |
| Installation Type | Wall Mounted / Pedestal Mounted |
| Utility Output | EV Charging Connector |
| Safety Protection | Overload, Short-Circuit, and Emergency Stop Protection |
| Color | Blue (Custom Colors Available) |
| Application | Distributed Public Utilities |
| Customization | Accepted |
JIYA team can help you select the right product based on your site requirements.
